The intrinsically safe batch controller Batching Master 110i/210i is designed for the control of truck loading applications in the hazardous area, ATEX zone 1. A lot of functionalities for exact and safe loading processes are available. Important information for a safe loading process are shown locally at the loading terminal. In the case of a problem, the loading process can be interrupted via an emergency stop switch.
Send Enquiry
* For continuous flow metering systems at pipelines or for flow measuring systems between two companies
* Custody transfer proofed metering systems for alcohol or alcohol based solvents
* Printout and storage of the counter values via the communication controller PCC 400
* Six counter blocks can work as batch counters or in fixed time intervals, like daily counters
* Flow conversion functions conform API 2540, tables A-C in metric units are available
* Dosing counter for safe area applications, e.g. in the food industries
* Automatic batch overrun and under batch compensation function
* Ramping functions for a safe and exact batching processes
* PID flow control function and Modbus interface optional
* Power supply: 24 VDC or 100-240 VAC
* Printout and storage of the custody transfer batch and loading protocols
* CSoftware for Batching Master, BC 20 and Pipeline Master available
* Communication to MySQL data bases or to terminal automation systems
* Modbus slave interface to supervisory systems
* Printout of lables for barrels or IBC's
* Dosing counters alto for the using in ATEX zone 1 available
* Control fuctions for the product flow rate available
* Ramping functions for a safe and exact batching processes
* Interface for communication with the PLC
* Power supply: 24 VDC or 100-240 VAC
* Consisting of flow meters, batch controllers, valves and panels with interface modules.
* Support from one vendor, from the engineering to the start-up
* Wide range of systems: From high-end truck loading systems to simple batching systems in the food industries.
* Documentation: Connection diagrams, dimensional drawings and intrinsically safe circuit verifications.
